Used Ideal 4855 Guillotine
Used Ideal 4855 Guillotine Latest Generation Ideal Electronic Programmable Guillotine Immaculate condition Comes with a 3 Month Warranty & HSE...
Products
Used/Pre-Owned Paper Guillotines
Used Ideal 5221-05EP Digicut Guillotine
- Fully refurbished Ideal 52cm guillotine with side tables
- Comes with a 3 Month Warranty & HSE Compliance Certificate
- 520mm cut width
- 520mm cut depth behind the blade (Ideal for SRA2 in half)
- 80mm cut height for up to a full ream of 500 sheets
- Power knife with hydraulic assistance (cut & release in under 1.5 seconds)
- Hydraulically powered clamp with fully adjustable clamping pressure
- Power back gauge with keypad – simply tap in your desired size and the back gauge moves to that position automatically
- Professional features such as a foot treadle for pre-clamping & false clamp plate
- 9 custom program with 9 cut steps
- Upgraded red optical cut line indicator
- EP models come complete with keypad controls for the back gauge with digital readout
- EP models have an electronically operated hand wheel for manual positioning of the back gauge
- Available to view in our Cheshire Showroom prior to purchase
Read MoreLess
£2,399.00 ex VAT
£2,878.80 inc VAT
Description
Specifications
We have available this used/pre-owned Ideal 5221-05EP Digicut Guillotine. The machine has been fully refurbished including a complete full strip down to the framework and re-built with all worn or tired components replaced. We have also maintained this machine since it was new, as a result, we know the full history of the machine.
This model will cut up to an SRA2 (640 x 450mm) in half and SRA3 in both landscape and portrait orientation. Safety guarded front and rear and complies with new European Safety Standards.
The Ideal 5221-05EP Digicut offers:
- 520mm cut width
- 520mm cut depth behind the blade (Ideal for SRA2 in half)
- 80mm cut height for up to a full ream of 500 sheets
- Power knife with hydraulic assistance (cut & release in under 1.5 seconds)
- Hydraulically powered clamp with fully adjustable clamping pressure
- Power back gauge with keypad – simply tap in your desired size and the back gauge moves to that position automatically
- Professional features such as a foot treadle for pre-clamping & false clamp plate
- 9 custom program with 9 cut steps
- Upgraded red optical cut line indicator
- EP models come complete with keypad controls for the back gauge with digital readout
- EP models have an electronically operated hand wheel for manual positioning of the back gauge
Comes with a new 6 Month Health & Safety Certificate, 2 Spare Blades, Tool Kit, Wooden Jogging Block and a 3 Month Parts & Labour Warranty.
Installation & Training can also be provided upon request – Extra charges may apply.
Available for demonstration in our Cheshire Showroom.
- Maximum Cut Width – 520 mm
- Maximum Cut Depth (Size behind the blade) – 520 mm
- Maximum Cut Height – 80 mm
- Minimum Cut Size – 22 mm
- Cutting Accuracy – 0.1mm
- Cycling Speed – 4-6 Cuts per Minute
- Production Capacity – 4-6 Hours Daily
- Programmable – Yes with 9 Programs
- Program Storage – Stored as Numbers 1-9
- Cut Positions in Each Program – 9
- Blade Type – Super High Speed Steel Only (18% Tungsten)
- Blade Drive – Electro-Mechnical
- Clamp Drive – Hydraulic
- Back Gauge Drive – DC Motor & Belt
- Blade Positioning – Micro Switch
- Clamp Positioning – Micro-Switch
- Back Gauge Measurement – Indexing Disc & Photo-interrupter
- Safety Curtain – Lid Guard
- Software – Ideal Own Software
- Power Requirements – 230Vac 13 Amp (Normal UK Socket)
- Power Usage – 1.1 KW/h Under Full Load
- Net Weight – 257Kgs
- Dimensions (H x W x D) 1,293 x 860 x 1,120mm (With Side Tables Width = 1,436mm)
