Used/Pre-Owned Paper Guillotines

Used Ideal 5222 Digicut Guillotine

  • Fully refurbished Ideal 52cm guillotine with side tables
  • Comes with a 3 Month Warranty & HSE Compliance Certificate
  • 520mm cut width
  • 520mm cut depth behind the blade (Ideal for SRA2 in half)
  • 80mm cut height for up to a full ream of 500 sheets
  • Power knife with hydraulic assistance (cut & release in under 1.5 seconds)
  • Hydraulically powered clamp with fully adjustable clamping pressure
  • Removable false clamp plate (reduces marking on delicate stock)
  • Power back gauge with keypad – simply tap in your desired size and the back gauge moves to that position automatically
  • Professional features such as a foot treadle for pre-clamping & false clamp plate
  • 99 custom program with 99 cut steps
  • Upgraded red optical cut line indicator
  • EP models come complete with keypad controls for the back gauge with digital readout
  • EP models have an electronically operated hand wheel for manual positioning of the back gauge
  • Available to view in our Cheshire Showroom prior to purchase
Read MoreLess

£3,750.00 ex VAT

£4,500.00 inc VAT

Description

Specifications

Ancillaries

We have available this used/pre-owned Ideal 5222 Digicut Guillotine. The machine has been fully refurbished including a complete full strip down to the framework and re-built with all worn or tired components replaced. We have also maintained this machine since it was new, as a result, we know the full history of the machine.

This model will cut up to an SRA2 (640 x 450mm) in half and SRA3 in both landscape and portrait orientation. IR Safety curtain on the front table gives unobstructed access to the cutting area for faster production. A 99 program keypad makes for effortless setup. Electronically controlled back gauge speeds up the cutting process.

The Ideal 5222 Digicut offers:

  • 520mm cut width
  • 520mm cut depth behind the blade (Ideal for SRA2 in half)
  • 80mm cut height for up to a full ream of 500 sheets
  • Power knife with hydraulic assistance (cut & release in under 1.5 seconds)
  • Hydraulically powered clamp with fully adjustable clamping pressure
  • Removable false clamp plate (reduces marking on delicate stock)
  • Power back gauge with keypad – simply tap in your desired size and the back gauge moves to that position automatically
  • Professional features such as a foot treadle for pre-clamping & false clamp plate
  • 99 custom program with 99 cut steps
  • Upgraded red optical cut line indicator
  • EP models come complete with keypad controls for the back gauge with digital readout
  • EP models have an electronically operated hand wheel for manual positioning of the back gauge

Comes with a new 6 Month Health & Safety Certificate, 2 Spare Blades, Tool Kit, Wooden Jogging Block and a 3 Month Parts & Labour Warranty.

Installation & Training can also be provided upon request – Extra charges may apply.

Available for demonstration in our Cheshire Showroom.

  • Maximum Cut Width – 520 mm
  • Maximum Cut Depth (Size behind the blade) – 520 mm
  • Maximum Cut Height – 80 mm
  • Minimum Cut Size – 22 mm
  • Cutting Accuracy – 0.1mm
  • Cycling Speed – 4-6 Cuts per Minute
  • Production Capacity – 4-6 Hours Daily
  • Programmable – Yes with 99 Programs
  • Program Storage – Stored as Numbers 1-99
  • Cut Positions in Each Program – 9
  • Blade Type – Super High Speed Steel Only (18% Tungsten)
  • Blade Drive – Electro-Mechanical
  • Clamp Drive – Hydraulic
  • Back Gauge Drive – DC Motor & Belt
  • Blade Positioning – Micro Switch
  • Clamp Positioning – Micro-Switch
  • Back Gauge Measurement – Indexing Disc & Photo-interrupter
  • Safety Curtain – IR Safety Curtain
  • Software – Ideal Own Software
  • Power Requirements – 230Vac 13 Amp (Normal UK Socket)
  • Power Usage – 1.5 KW/h Under Full Load
  • Net Weight – 352Kgs
  • Dimensions (H x W x D) 1,310 x 950 x 1,090mm (Width with Side Tables = 1,650mm)
